FEATURES
• Achieve complex contouring with the American-made laser. This enables the precise cone shaping and carving of diamonds into various intricate shapes.
• Experience convenience and flexibility as you effortlessly cut fancy and customized diamond shapes in one setup.
• Intelligent features for processing different applications at a single set-up.
• Fully automatic system provides better production without high skilled manpower.
• Smart intelligent software detects the stones symmetry and accordingly selects the best cutting parameter.
• Cuts fancy shapes and customized shapes at a single setup.
•. Almost negligible breakage rate due to RTLS (Real Time Laser System).
• Precision laser operation due to stable beam delivery.
• Total protection of diamond using peak power control.
Technical Specification
Laser Source | SPAQ 75W CW | |
Laser Type | DPSSL | |
Wavelength | nm | 1064 |
Beam Mode | TEM00 | |
Output Power | watt | ≤ 28 W @ 6 kHz |
CNC Table | mm | 120 * 120 |
Resolution | micron | ±1 |
Repeatability | micron | ±6 |
Accuracy | micron | ±5 |
Drive Type | AC SERVO | |
Z Axis Travel | mm | 50 |
Power Supply | 1 Phase, 15 Amp | |
Power Consumption | kW | 2.2 |
Operating Environment | ||
Temperature / Humidity | 20 – 30 / < 60% | |
Coolant Requirement | 4 – 6 | |
Coolant Storage | litre | 10 |
Dimension | mm | 1360 * 730 * 1390 |
Computer System | Intel Core i3 based CPU or Higher |
*Technical specification are subject to change without prior notice.
