FEATURES
• Specially designed laser for processing different applications at a single set-up.
• Almost negligible breakage rate due to RTLS (Real Time Laser System).
• Precision laser operation due to stable beam delivery.
• Fully automatic system provides better production without high skilled manpower.
• Smart intelligence software detects the stone symmetry and accordingly selects the best cutting parameter for the operation.
• Auto frequency.
• Single-phase power usage.
• Total protection of diamond using peak power control.
• The machines are constructed by reputable engineers, ensuring reliability and enabling maximum productivity.
• Precision laser operation due to stable beam delivery.
Technical Specification
| Laser Source | Multi Diode Pumped Fiber Laser | |
| Wavelength | nm | 1064 ± 10 |
| Beam Mode | M2<1.2 | |
| Laser Power | watt | 20 |
| Laser Class | IV | |
| CNC Table | mm | 120*120 |
| Resolution | micron | ±1 |
| Repeatability | micron | ±6 |
| Accuracy | micron | ±5 |
| Drive Type | AC SERVO | |
| Z Axis Travel | mm | 50 |
| Power Supply | 1 Phase, 4 Amp | |
| Power Consumption | kW | 0.7 |
| Operating Environment | ||
| Temperature / Humidity | °C/RH | 20-30 / < 60% |
| Dimension | mm | 950*730*1390 |
| Computer System | Intel Core i3 based CPU or Higher |
* Technical specifications are subject to change without prior notice.
